ARBOO's rugged portable computer series adopts unique aluminum-magnesium alloy design, special rubber wrap angle, sturdy, anti-vibration, drop resistance, mature products and stable quality. The product integrates the integration and portability of the notebook, the trolley case design, high-capacity battery; multi-PCI/PCle or PXI/PXle function card expansion position, easy to set up various test and monitoring systems; for harsh indoor and outdoor environments Superior adaptability: It can meet the application requirements of different industry fields.
Series features - multiple extensions, strong environmental adaptability
1. Fanless design of all-aluminum-magnesium alloy, rubber wrap angle reinforcement
2, PCI / PCle or PXI / PXle function card multi-expansion bit
3, high brightness low temperature LCD screen design
4, equipped with a custom trolley case, in line with portable ergonomic design
5, adapt to high and low temperature and harsh environment, "three defense" design
product description
The industry's first 8-slot 3U PXI / PXIe platform with built-in Intel® CoreTM I-series high-performance quad-core processors designed for test and measurement applications; its high-bandwidth backplane provides up to 1GB/s of dedicated bandwidth per slot. For efficient operation; with 4 PXI slots, PXI xpress slots, 2 PXI/PXI Express hybrid slots. Provides PXI/PXIe standard platforming services to build the best portable solution for a wide range of applications. It is suitable for applications such as measurement, test and monitoring by integrating third-party hardware and software such as NI, Agilent, and Aeroflex.
Main feature
8-slot PXI/PXIe backplane
Compatible with PXI, PXIe, cPCI, and cPCI Express modules
Up to 1GB/s dedicated bandwidth per slot and over 3GB/s system bandwidth
DVI 15.1'' high resolution LCD/LVDS
DC and AC dual redundant power input
Power module for easy removal
Application field
Military, aviation, aerospace, electricity, communications, energy
Specifications
product description
The most classic PCI/PCIe portable instrument computer classic portable instrument computer with Intel core processor, the platform is very scalable; ultra-quiet fan modular design, easy to clean and replace; two 2.5-inch hard drive extraction box, more Easy to increase storage space; with industrial-grade integrated motherboard, it can expand multiple PCI or PCIex1, PCIex4, PCIex8 and PCIex16 and other general-purpose functional boards; Designed for users in various industries, its integrated design in the field Requirements, in line with the needs of many users.
Main feature
All-aluminum-magnesium alloy case, modular silent fan design
Highlight low temperature 15.1''LCD, 1024x768 resolution (optional 1920x1080 resolution)
Choice of 4 or 10 full-length expansion card designs
2 2.5'' hard drive extraction boxes
Built-in slot-loading DVD burner
Industrial mechanical waterproof keyboard (more than 50 million times)
Patented anti-vibration pressure card design
Application field
Communication, measurement and control, energy, education
Specifications
product description
ARBOO CPC-9220 all-aluminum-magnesium alloy fanless design rugged computer, the industry's first all-aluminum-magnesium alloy fanless design portable machine, user-friendly industrial design, very suitable for working in harsh indoor and outdoor environments. The CPC-9220 integrates a rich set of I/O expansion interfaces. All expansion cards are ruggedized for field surveys and on-board, with built-in UPS backup rechargeable batteries and efficient power management software, integrated with third-party software and hardware. It is very convenient to build a variety of test and monitoring systems for a variety of portable applications.
Main feature
All-aluminum-magnesium alloy fanless design
High-light low temperature 12.1'' LCD display with dual display
2 standard PCI slots, 1 mini PCI slot expansion
Rich I/O expansion interface design
Built-in 2 3000mAH lithium batteries with built-in power battery management software
Application field
Military, aviation, aerospace, shipborne, electric power
Specifications
product description
The ARBOO CPC-9520 is an all-aluminum fanless design laptop with a user-friendly industrial design that ensures high integration, portability, and ruggedness. The product integrates a rich I/O expansion interface with high performance 15.4. “LCD screen and anti-vibration hard disk, equipped with rechargeable battery. This product can provide complete customized service according to different needs. By integrating third-party software and hardware, engineers can easily build various test and monitoring systems for various types. Different portable applications.
Main feature
All-aluminum fanless design, reinforced anti-collision wrap angle
Highlight low temperature 15.4''LCD, 1280x800 resolution
1 PCI expansion slot + 1 PCIex16 expansion slot (can be customized to choose 2 standard PCI slot expansions)
2 GigE, 1 HDMI, 1 DVI-I, 1 VGA, 4 COM, 4 USB 2.0
Built-in 9000mAH lithium battery
Built in 1 DVD burner
Application field
Military, aviation, aerospace, shipborne, electric power
Specifications
product description
The most classic PCI/PCIe portable computer This product is designed and developed for users in various industries. It is equipped with Intel's latest multi-core processor. Its platform expansion performance is very superior. The ultra-quiet fan is modular design, which is very convenient for cleaning and replacement. Two hard drive trays add storage space and expand to seven PCI or PCIe specification functional boards for new engineer development. The integrated design requirements in the field meet the needs of many users.
Main feature
All-aluminum-magnesium alloy cabinet design, silent fan design
Highlight low temperature 17'' LCD, 1280x1024 resolution
7 full-length expansion card designs
2 2.5'' or 3.5'' hard drive trays
Built-in slot-loading DVD burner
Industrial mechanical keyboard (more than 50 million times)
Application field
Communication, measurement and control, energy, education
Specifications
product description
This product is a rugged portable computer with all-aluminum design. It can expand 7 6U cPCI slots and support post-cPCI IO modules. It is suitable for all kinds of harsh indoor and outdoor environments. The user-friendly industrial design ensures high integration. Portable, rugged and so on, engineers can easily build a variety of test and monitoring systems.
Main feature
All aluminum alloy reinforcement design
Highlight low temperature 17â€, 1280x1024 resolution
7 6U cPCI expansion slots
1 2.5'' hard drive tray
Built-in slot-loading DVD burner
Industrial mechanical keyboard (more than 50 million times)
460W industrial power supply
Patented anti-vibration locking design
Application field
Military, aviation, aerospace, electricity, communications, energy
Specifications
product description
The product is a rugged cPCI portable computer designed with aluminum-magnesium alloy. It is suitable for all kinds of harsh indoor and outdoor environments. The humanized industrial design ensures high integration, portability and robustness. It is equipped with a 4-slot 6U cPCI backplane. The product integrates a rich I/O expansion interface, making it easy for engineers to build a variety of test and monitoring systems for a variety of portable applications.
Main feature
All-aluminum-magnesium alloy design, special anti-collision wrap angle design
Highlight low temperature 15.4" LCD, 1280x800 resolution
4-slot 6U cPCI backplane
250W industrial power supply
Industrial mechanical keyboard (more than 50 million times)
Application field
Military, aviation, aerospace, electricity, communications, energy
Specifications
